BrickStor High-Speed Data Recorder – Network
Capture and replay ultra-wideband RF data at terabit speeds without compromising security or performance
Introducing BrickStor HDR-N
RackTop’s BrickStor High-Speed Data Recorder Network (HDR-N) series is a software-defined technology stack that leverages off-the-shelf hardware with Gen5 NVMe storage and is flexible enough to function from the tactical edge to the datacenter.
Benefits
BrickStor HDR adds data recording capabilities to RackTop’s robust network-attached storage product line. The HDR is a cost-effective solution with flexible form factors and scalable capacities for any requirement. The solution supports high-speed Ethernet connectivity with security, and a unique scale-out design that supports the aggregation of multiple data recorders into a single, logical recording system. BrickStor HDR was built specifically to address the recording and playback of any network radio frequency (RF) signal, including ultra-wideband RF signals over Ethernet, at extreme speed and with lossless integrity.
Features
Multi-Protocol RF Ingest
Brickstor HDR-N supports multi-protocol RF ingest, enabling seamless integration into various environments. It offers compatibility with Multicast UDP, Unicast UDP, and VITA 49 over Ethernet, allowing users to capture wideband RF signals using standardized IP-based data flows. This approach ensures interoperability across systems and simplifies managing high-throughput signal acquisition.
Record & Playback Functionality
With built-in recording and playback capabilities, Brickstor HDR-N allows users to capture and store wide band signals in real-time and then replay them at full fidelity whenever needed. This eliminates the need to recapture signals, enabling users to analyze, test, and validate RF environments repeatedly and consistently. It’s ideal for lab environments, field deployments, and everything in between.
Cyber Secure NAS Integration
The solution contains built-in cybersecurity and NAS (network-attached storage) functionalities at its core. Utilizing dual layers of FIPS AES-256 encryption allows users to establish a strong and quantum-resistant security framework. Users have the flexibility to manage encryption keys either through an internal key manager or an external key manager that complies with KMIP standards, ensuring adherence to enterprise-level security protocols.
Massive Storage in 1U
Brickstor HDR-N is designed for high-density environments and offers 960 TB of raw storage capacity within a single rack unit. This capacity is perfect for capturing and storing large RF datasets while maintaining speed and reliability. Its scalable architecture allows for expansion as data needs increase, and the compact 1U form factor minimizes the physical footprint in your data center or deployment environment.
Blazing Network Speeds
With up to 800 Gb/s of network connectivity in just 1U, the solution is ideal for high-bandwidth RF ingest and playback. It allows for the aggregation of multiple systems to achieve Terabit speed, ensuring efficient data handling. Various NIC options provide flexibility for diverse network architectures, enabling users to eliminate network bottlenecks continuously and keep up with ultra-wideband data streams.
Deployment Flexibility
Brickstor HDR-N is designed for easy integration into a wide range of environments, occupying just 1U of rack space. Brickstor supports clustering for larger or distributed deployments, and ruggedized options are available in harsh or mobile conditions. Its versatility makes it ideal for various applications, including ground stations, electronic warfare test labs, telemetry ranges, and more.
User-Friendly Management Tools
The solution offers an intuitive web-based GUI and a REST API, making system configuration and monitoring straightforward for users of all skill levels. Its advanced scheduling capabilities allow for autonomous record and playback operations, enabling seamless task management without constant oversight. Comprehensive logging and auditing features ensure data integrity and compliance, providing users a reliable way to track changes and maintain accountability in their operations.
Data Portability
Hot-swappable Disk Packs are designed to efficiently offload and securely carry data from the field, ensuring reliable data management. Users can easily export data to an external mount point, facilitating seamless integration with other systems. Brickstor HDR-N incorporates detailed logging and auditing features that uphold data integrity and compliance, assuring users that their data is accessible and protected.
Use Cases
Radar Recording and playback
Wideband RF Recording and playback
Electronic Warfare (EW) & SIGINT: Capture and replay complex RF scenarios to train systems and refine algorithms
Telecommunications & Satellite: Validate signals end-to-end with precise record and playback
Cyber Mission Forces threat-hunting kit: Record network activity and run advanced analytics against recorded data
Technical Details
| Specification | Details |
| Protocols | Multicast/Unicast UDP, VITA 49 over Ethernet |
| Network Connectivity | Up to 800 Gb/s (multiple NIC options) |
| Storage Capacity | 960 TB in 1U |
| Data Throughput | High-speed recording/playback up to line rate |
